SPECIFICATION
Dimensions 1350 x 683 x 1455
Weight 305 kg Net
Power supply 380V 50/60 Hz, 3 phases
220V 50/60 Hz, 3 phases (optional)
Motor power 3,7 kW, controlled by inverter
Max high pressure 2500 bar
Test oil tank 42 l
BASIC FEATURES
• Common rail injectors testing (4 channels)
• Delphi C2i/C3i/C4i coding
• Bosch electromagnetic injectors IMA coding
• Bosch piezo injectors ISA/IMA coding
• Denso electromagnetic and piezo injectors QR
coding
• Siemens/Continental piezo injectors IIC coding
• NOP and MST measuring
• I-Art and rail pressure sensors testing
• 4-pin CRIN 4.2 injector testing
• Automatic cooling/heating system for test oil
temperature control
OPTIONAL FEATURES
• PCV and RAIL testing
• VCC and NCC time measurement for CRI 3-25, 3-27
injectors
INCLUDED ACCESSORIES
• 4x TD-7100-2xx Set of pipes for CR injectors
• 4x TD-7100-3xx Set of cables for CR injectors
