SPECIFICATION
"Dimensions 1350 x 683 x 1455
Weight 430 kg Net
Power supply 380V 50/60 Hz, 3 phases
220V 50/60 Hz, 3 phases (optional)
Motor power 7,5 kW, controlled by inverter
Max high pressure 2000 bar / 2500 bar (optional)
Supply pressure 0 - 6 bar
Test oil tank 42 l
Lubrication oil tank 5 l (optional)"
BASIC FEATURES
• Common rail pumps testing
• Rail pressure sensors testing
• Automatic cooling/heating system for test oil
temperature control
• Siemens/Continental piezo injectors IIC coding
• NOP and MST measuring
• I-Art and rail pressure sensors testing
• 4-pin CRIN 4.2 injector testing
• Automatic cooling/heating system for test oil
temperature control"
OPTIONAL FEATURES
• PCV and RAIL testing
• Pumps with angle control testing (DHP1.1, HP0,
HP5..7, CAT, CP2, CP4E etc)
• Lube oil system for heavy duty pumps
INCLUDED ACCESSORIES
TD-7000-0xx Set of flanges and couplings for CR
pumps
• TD-7000-1xx Set of cables for CR pumps
