SPECIFICATION
| Dimensions 1350 x 683 x 1455 Weight 450 kg Net Power supply 380V 50/60 Hz, 3 phases 220V 50/60 Hz, 3 phases (optional) Motor power 7,5 kW, controlled by inverter Max high pressure 2000 bar / 2500 bar (optional) Supply pressure 0 - 6 bar Test oil tank 42 l Lubrication oil tank 5 l (optional) |
BASIC FEATURES
• Common rail pumps testing
• Common rail injectors testing (1 channel)
• Bosch electromagnetic injectors IMA coding
• Bosch piezo injectors ISA/IMA coding
• Denso electromagnetic and piezo injectors QR
coding
• Siemens/Continental piezo injectors IIC coding
• NOP and MST measuring
• I-Art and rail pressure sensors testing
• 4-pin CRIN 4.2 injector testing
• Automatic cooling/heating system for test oil
temperature control"
Â
OPTIONAL FEATURES
• PCV and RAIL testing
• VCC and NCC time measurement for CRI 3-25, 3-27
injectors
INCLUDED ACCESSORIES
• TD-7000-0xx Set of flanges and couplings for CR
pumps
• TD-7000-1xx Set of cables for CR pumps
• TD-7100-2xx Set of pipes for CR injectors
• TD-7100-3xx Set of cables for CR injectors
